SQ-lab saddle 602 Ergolux active 2.0

SQ-lab saddle 602 Ergolux active 2.0

The SQlab 602 Ergolux® Active 2.0 is the proven trekking and touring saddle for medium to long distances. Compared to the very firm and slim ERGOWAVE® models, the 602 Ergolux® Active 2.0 offers more padding volume, allowing the foam to be slightly softer. The contact area is significantly larger than before thanks to the double wave design, resulting in less sinkage of the sit bones. The disadvantages that can typically occur with softer foams due to the sit bones sinking in are therefore eliminated with the Ergolux®.

The first stage supports the rear of the sit bones, providing perfect support and thus improving power transfer to the pedals. The second stage optimally supports the already relieved ischial tuberosities, ensuring the best possible pressure distribution. The perineum and the front of the pubic bones and pubic arch receive more freedom of movement thanks to the even lower saddle nose. The proven SQlab Active System allows the saddle to follow the pedaling motion, increasing comfort, protecting the intervertebral discs, and further reducing pressure on the sit bones.

Thanks to the proven SQlab Active System, the saddle follows the pedaling motion, increasing comfort, protecting the intervertebral discs, and further reducing pressure on the sit bones. The flex and Active movement can be adjusted to the rider's weight using the comfort sticks in the Active damper.

Test winner: "Once you get used to the stepped shape, the 602, with its firm padding and Active System, provides exceptional seating comfort. It supports the sit bones and relieves pressure on the perineum like no other." aktiv Radfahren 03/2020

This version has 140 mm of effectively usable seating surface.

• SQlab seating position
• Moderate: Saddle and handlebars at approximately the same height correspond to a moderate riding position. Both mountain bikers and sporty trekking cyclists usually adopt this position.

Slightly bent: The average trekking and city cyclist usually sits slightly bent over on their bike. But enduro riders also often sit in this rather upright position.

Features

• Tested for harmful substances – TÜV Süd
• Unisex saddle
• SQlab stepped saddle concept: The lower saddle nose relieves pressure on the perineal area and sensitive structures in both men and women, distributing the pressure across the sit bones.
• Ergolux®: This is the comfort version of the successful SQlab Ergowave® saddle shape. It's designed for cyclists who prefer a more upright riding position on their touring, everyday, city, or trekking bike.
• Saddle width system: SQlab saddles are available in one to five different widths. The correct saddle width is determined using the SQlab sit bone measurement. Alternatively, you can also measure your sit bone width at home.
• SQlab MaxContact®: The flattened, narrow saddle nose offers a much larger contact area and therefore greater pressure distribution than conventional saddles.
• The effective saddle width: The specified saddle width always refers to the effectively usable seating area, not the overall width. All SQlab saddles utilize the maximum usable area and minimize the amount of width wasted through excessive curvature.
• E-bike ready: The saddle is suitable for use on e-bikes.
• Perfect grip: The raised rear provides additional support to the rear and ensures direct power transmission to the pedal.
• Comfortable seating position: The wave-shaped elevation of the Ergolux® saddles, extending from the rear to the front, is perfectly suited to the typically bulbous ischial tuberosities. The larger, less concentrated contact area ensures optimal pressure distribution.
• Lower saddle nose: A lower saddle nose puts less pressure on sensitive areas. This applies to both men and women.
• Deep and flat: The flat, only very slightly curved shape of the saddle nose results in a maximum contact area with correspondingly low pressure. This also makes the nose narrow and reduces lateral friction to a minimum.

Relation

• microfiber
• Water-repellent: water-repellent cover material

upholstery

• Light Foam

saddle shell

• SQlab Active saddle technology: The Active saddle allows for physiologically correct movement of the pelvis, which relieves the intervertebral discs and minimizes pressure on the sit bones.

saddle stays

• CrMo saddle rails

Technical data

• Intended use: Trekking
• Length (mm): 280
• Weight (g): 440
• Hardness in SQ-Shore: 45
• Perineal relief in %: 70
• Strut material: CrMo (solid)
• Saddle shell material: Polypropylene composite (PP)
• Padding material: Light Foam
• Cover material: Microfiber
• Maximum load in kg: 130
• maximum tightening torque in Nm: 18

Scope of delivery

• 1 saddle
